Geberit Duofix 112cm WC Frame with Sigma Concealed Cistern 12cm 111.384.00.6
This product is designed for use in drywall construction and is suitable for both part-height and full-height prewall installations, as well as full-height installation walls. It is compatible with Geberit Duofix system walls in both part and full-height configurations. The system is intended for wall-hung WCs with connection dimensions compliant with EN 33:2011 and supports toilet projections of up to 62 cm. It is also suitable for floor constructions with heights ranging from 0 to 20 cm.Features:
- Statically self-supporting frame, protected against corrosion with powder coating
- Frame with ø 9 mm drilling holes for fastening in wood frame construction
- Frame prepared for support brackets for WC ceramic appliances with small contact surfaces
- Galvanized feet
- Feet adjustable 0-20 cm
- Non-slip leg supports
- Rotatable foot plates
- Foot plate depth suitable for installation in U-profiles UW 50 and UW75 and Geberit Duofix system rails
- Connection bend can be mounted without tools at different depths, adjustable range 45 mm
- Fastening for connection bend, sound-absorbing
- Concealed cistern with front actuation
- Concealed cistern, fully insulated against condensation
- Cistern fulfils standard requirements in accordance with EN 14055, Class II
- Immediate post flush possible with factory setting
- Tool-free installation and maintenance work on concealed cistern
- Water supply connection on the rear or top centre
- Protection cover box for service opening protects against moisture and dirt
- Protection box for service opening can be cut to length
- With conduit pipe for feed pipe for Geberit AquaClean shower toilets and for connection cable
- Fastening option for electrical connection
- Power & Connect Box mountable
Main product features:
- Self-supporting, corrosion-resistant frame with powder coating for durability and stability.
- Height-adjustable galvanized feet (0-20 cm) with non-slip supports and rotatable foot plates.
- Tool-free installation and maintenance of the concealed cistern.
- Front-actuated, fully insulated concealed cistern to prevent condensation.
- Compliant with EN 14055, Class II standard for performance and quality.
- Tool-free, adjustable connection bend with a 45 mm depth range and sound-absorbing fastening.
- Compatible with Geberit Duofix system rails and UW 50/UW 75 profiles for flexible installation.
- Immediate post-flush capability with factory settings.
Description
This product is designed for use in drywall construction and is suitable for both part-height and full-height prewall installations, as well as full-height installation walls. It is compatible with Geberit Duofix system walls in both part and full-height configurations. The system is intended for wall-hung WCs with connection dimensions compliant with EN 33:2011 and supports toilet projections of up to 62 cm. It is also suitable for floor constructions with heights ranging from 0 to 20 cm.Features:
- Statically self-supporting frame, protected against corrosion with powder coating
- Frame with ø 9 mm drilling holes for fastening in wood frame construction
- Frame prepared for support brackets for WC ceramic appliances with small contact surfaces
- Galvanized feet
- Feet adjustable 0-20 cm
- Non-slip leg supports
- Rotatable foot plates
- Foot plate depth suitable for installation in U-profiles UW 50 and UW75 and Geberit Duofix system rails
- Connection bend can be mounted without tools at different depths, adjustable range 45 mm
- Fastening for connection bend, sound-absorbing
- Concealed cistern with front actuation
- Concealed cistern, fully insulated against condensation
- Cistern fulfils standard requirements in accordance with EN 14055, Class II
- Immediate post flush possible with factory setting
- Tool-free installation and maintenance work on concealed cistern
- Water supply connection on the rear or top centre
- Protection cover box for service opening protects against moisture and dirt
- Protection box for service opening can be cut to length
- With conduit pipe for feed pipe for Geberit AquaClean shower toilets and for connection cable
- Fastening option for electrical connection
- Power & Connect Box mountable
Main product features:
- Self-supporting, corrosion-resistant frame with powder coating for durability and stability.
- Height-adjustable galvanized feet (0-20 cm) with non-slip supports and rotatable foot plates.
- Tool-free installation and maintenance of the concealed cistern.
- Front-actuated, fully insulated concealed cistern to prevent condensation.
- Compliant with EN 14055, Class II standard for performance and quality.
- Tool-free, adjustable connection bend with a 45 mm depth range and sound-absorbing fastening.
- Compatible with Geberit Duofix system rails and UW 50/UW 75 profiles for flexible installation.
- Immediate post-flush capability with factory settings.
Specifications
Geberit
WC Frames & Plates
WC Frames
111.384.00.6
Toilet Frame
