Geberit Duofix 82 cm frame with Omega concealed cistern 12 cm for wall-hung WC 111.004.00.4
The Geberit Duofix frame allows bathroom designers to create eye-catching new bathrooms ideas from the bare minimum without expensive structural work. The Omega range allows the flush plate to be positioned to either the front of the top for ultimate flexibility Hidden behind walls and tiles, the Geberit Duofix supports wall hung sanitaryware and includes an integral cistern. The sturdy Aquamarine metal frame has been designed to support wall hung sanitaryware without the need for supporting walls The result is a clean and modern finish with no visible pipework. The Geberit Duofix frame is the backbone to Geberit's bathroom system
Main product features:
- With Omega 12cm top or front operated cistern
- Cistern set to a 5.8 - 3L flush, which can be adjusted to 4.5 / 6 / 7.5L
- Tool-free installation and maintenance
- For wall-hung WCs with projection up to 62 cm
- For floor constructions 0-20 cm
Description
The Geberit Duofix frame allows bathroom designers to create eye-catching new bathrooms ideas from the bare minimum without expensive structural work. The Omega range allows the flush plate to be positioned to either the front of the top for ultimate flexibility Hidden behind walls and tiles, the Geberit Duofix supports wall hung sanitaryware and includes an integral cistern. The sturdy Aquamarine metal frame has been designed to support wall hung sanitaryware without the need for supporting walls The result is a clean and modern finish with no visible pipework. The Geberit Duofix frame is the backbone to Geberit's bathroom system
Main product features:
- With Omega 12cm top or front operated cistern
- Cistern set to a 5.8 - 3L flush, which can be adjusted to 4.5 / 6 / 7.5L
- Tool-free installation and maintenance
- For wall-hung WCs with projection up to 62 cm
- For floor constructions 0-20 cm
Specifications
10kg
820mm
500mm
140mm
Geberit
WC Frames & Plates
WC Frames
12cm
0.1-10 Bar
82cm
25°C
111.004.00.4
Toilet Frame
Geberit Omega
