DAB Evo VS 65/150 B Hot Water Circulating Pump 60185007H

(Code: 1144531)
DAB Pumps
Domestic Hot Water circulating pump
£ 139.99
2600g
@import url(https://fonts.googleapis.com/css?family=Lato:100,400); #the-final-countdown { background: #333; font-family: 'Lato', sans-serif; text-align: center; color: #eee; text-shadow: 1px 1px 5px black; padding: 1rem 0; font-size: 3rem; border: 1px solid #000; }
  1. Description of DAB Evo VS 65/150 B Hot Water Circulating Pump 60185007H:



    Pump for hot for water circulation in pressurised closed circuit, or open circulation type, domestic heating and air conditioning systems. Also suitable for solar power systems. Single body formed of the bronze hydraulic unit, die-cast aluminium motor casing and technopolymer impeller. Special single model design to replace all 4, 5 & 6 Metre head traditional models.

    Ceramic driving shaft mounted on graphite brushings lubricated by the pumped liquid itself. Stainless steel protective rotor sleeve, stator sleeve and closing flange. Ceramic thrust bearing, E.P.D.M. "O” rings. The two-pole or four-pole asynchronous motor with wet rotor is self-protected for resistance. No overload protection required.
  2. Features of DAB Evo VS 65/150 B Hot Water Circulating Pump 60185007H:

    ✔ Self-protected for resistance, no overload protection required
    ✔ Ceramic thrust bearing, E.P.D.M. "O” rings
    ✔ Stainless steel protective rotor sleeve, stator sleeve and closing flange
    ✔ Operating range: from 0,5 a 3,6 m3/h with pressure head of up to 6m
    ✔ 3 year manufacturers warranty
  3.
  4. To find out more details about the product. Have a look at the following product spreadsheet.
